Brinn

CAN'T FIND YOUR PART? CALL 0491 845 484 TO ORDER
# PART NO DESCRIPTION
KIT1 BRI70041 Rebuild Kit
1 71001 5/16-18 x 7/8" SHCS
2 71002 Roll Pin
3 71003 O-Ring (6.1mm x 3.0mm)
4 71004 Detent Spring
5 71005 Lockout Spring
6 71006 Lockout Detent Ball
7 71007 Vent Assembly
8 71008 Bearing
9 71009 1/4-20 x 1" SHCS
10 71010 Retaining Ring
11 71011 Oil Seal
12 71012 Machined Bushing
13 71013 Thrust Washer (0.060-0.063 Thick)
14 71014 Cage Bearing
15 71016 Clutch Return Spring
16 71017 Steel Clutch Pressure Disc
17 71018 Metallic Friction Disc
18 71019 Cage Bearing
19 71020 Bunting Bearing
20 71021 Rear Clutch Disk (183 Thick)
21 71022 Retaining Ring
22 71023 Bearing
23 71024 Retaining Ring
24 71025 Thrust Washer (154-157 Thick)
25 71026 Needle Thrust Bearing
26 71027 Bleeder Assembly
27 71029 Roll Pin
28 71030 Clutch Actuator Pin
29 71031 Roll Pin
30 71032 Thrust Washer (092-095 Thick)
31 71033 Needle Thrust Bearing
32 71034 1/4-20 x 1/4" SHCS
33 71035 Clutch Piston O-Ring
34 71037 Grease Fitting 1/8" NPT
35 71038 1/4-20 X 1/2"
36 71040 Rear Seal & Bushing Kit
37 71041 Fill Plug
38 71042 7/16-14 x 1 1/2" SHCS
39 71043 5/16 Lock Washer
40 71046 O-Ring
41 71049 Cage Bearing
42 71059 Magnetic Drain Plug
43 71061 7/16 Lock Washer
44 71063 O-Ring 70 Durometer Nitrile
45 71064 Brass Tip Dog Point Set Screw
46 71065 Set Screw
47 72001 Cover Shift Plate
48 72010 Main Case (Aluminum/Magnesium)
49 72003/72001 Output Housing (Aluminum/Magnesium)
50 72004 Front Retainer
51 73001 Reverse Shift Fork
52 73002 High/Low Shift Fork
53 73003 High/Low Lever
54 73005 Reverse Shift Rod
55 73006 First/High Shift Rod
56 73007 Forward Clutch Ring
57 73009 Thrust Race Intermediate Shaft
58 73010 Guide Shaft
59 73011 Reverse Idler Shaft
60 73012 Output Shaft Bearing Spacer
61 73013 Cylinder Housing
62 73014 Intermediate Shaft Retainer
63 73015 Piston - Clutch Piston
64 73016 Lockout Detent Pin
65 73017 First Gear Spacer
66 73020 Reverse Idler Shaft Cover
67 73021 Reverse Shift Lever
68 73022 3/8"-24 Nut
69 73023 3/8 Lock Washer
70 73024 High/Low Lever
71 73025 5/16-18 x 5/16 Set Screw w/Nylon Patch
72 73026 Plug
73 73029 1/8 x 1 Roll Pin
74 73031 Lower Reverse Spacer
75 74002 Input Mesh Gear Driven
76 74004 Reverse Idler Gear
77 74006 Clutch Housing
78 74007 Reverse Gear Driven
79 74008 Intermediate Shaft
80 74010 Output Shaft
81 74011 First Gear Driven
82 74012 First Gear Driving
83 74020 Input Shaft
84 74021 High/Low Dog Ring
